| Brand | TIANMA |
| Model | TM030LDHT3-00 |
| Size | 3.0inches |
| Resolution | 240(RGB)×400 |
| From | 0.162x0.162mm |
| Range | 38.88x 64.8mm |
| Size | 47.28x76.4x2.4mm |
| View | T70/B45/L45/R50 |
| Interface | RGB+3SPI/CPU |
| Brightness | 260nits |
| Contrast | 150:1 |
| Weight | 17.5g |
| Voltage | 2.8V |
| Backlight | 5LED |
| Temperature | -20～+70℃ |
| Preservation | -30～+80℃ |
| Touch | |
| Specification | Download |
